PERFORMANCE

Featuring the latest in 2-stroke technology, the 2024 KTM 65 SX sets the benchmark at the starting gate. Besides using the lightest and most durable materials, the engine features a pressure-controlled exhaust valve that delivers top-level performance through its manual 6-speed transmission. A new mounting concept for the crankshaft also makes for easier maintenance.

CYLINDER

The 2024 KTM 65 SX features a high-performance cylinder made from lightweight and durable aluminum that incorporates a pressure-controlled exhaust valve (PCEV), providing unrivaled performance.

TRANSMISSION

The transmission on the 2024 KTM 65 SX has undergone a complete refresh. From general durability to overall quality, the transmission maintains the same legendary performance but now presents as a more comprehensive and hardy unit. This is paired with a new forged shift lever offering improved functionality, while the reliable and light hydraulic clutch system guarantees even wear and near maintenance-free operation.

SPARK PLUG

There's no more worrying about breaking the plug, thanks to the 2024 KTM 65 SX featuring a new spark plug from BRISK with a longer thread. Also, thanks to this innovation from BRISK, the part number is printed on the spark plugs for easy reading – even while screwed in place.

EASY SERVICING

Servicing and general maintenance are made simple, thanks to draining noses for liquids and added service markers on the engine (▲) that clearly show where to use washers, making maintenance and service easier than before. Nm markings clearly show how to tighten relevant screws to avoid overtightened or too loose bolts. Many of the screws on the engine case have also been unified to the same screw length on the engine case.

TANK

The KTM 65 SX is ready to fuel the fire in your little ripper with an updated tank design to compliment the new frame concept and bodywork.

AIRBOX AND FILTER

An all-new airbox concept features a conventional suction sleeve made from a hard-wearing polyamide instead of rubber and a Twin Air filter mounting system that now features snap locks for easy and intuitive mounting. The Twin Air filter is also placed under the seat and is easily accessible without any tools by simply removing the seat. It also features improved dirt intrusion resistance, with no more dirt falling into the intake tract when changing the filter.

ERGONOMICS

The all-new bodywork of the 2024 KTM 65 SX is the perfect example of KTM's commitment to providing the ultimate starting point for young racers. Mimicking the full-size KTM SX range, the KTM 65 SX features the same advancements found in the larger KTM SX classes. Slimmer, sleeker, and better suited to standing on the pegs, the side panels now work much better with young riders’ boots, allowing proper squeezing of the bike when standing up. The front number plate incorporates plastic flaps to protect the lower triple clamps from roost. At the same time, the tank spoiler features a bicomponent technology featuring the KTM-specific texture on the upper part. Side number plates are kept as close to the frame as possible, with the general seat line sitting slightly flatter compared to the old generation.

HANDLEBARS & GRIPS

Hold on tight! The high-quality, tapered, black handlebar is made of lightweight aluminum alloy and ensures top stability, vibration damping, and control. It has been designed specifically with 65cc riders in mind, featuring an entirely new bend and profile for a more READY TO RACE body position. ODI grips are mounted on the left side, while a vulcanized ODI grip is mounted on the right-side throttle assembly, with a crash pad on the handlebar protecting the rider from rough contact.

WHEELS & TIRES

Rolling off the race rig and into the pit lane, the 2024 KTM 65 SX uses lightweight, black anodized, aluminum rims like the full-size KTM SX range. These provide the highest levels of strength and reliability, while MAXXIS MX-ST tires deliver outstanding performance on any terrain and exceptional straight-line stability.

FOOTPEGS

All-new, “no-dirt” footrests offer a bigger surface area for improved grip while standing on the pegs and are less susceptible to hooking up in deep ruts, take-offs when scrubbing, or track barriers.

SUSPENSION

Featuring the latest in suspension technology, the KTM 65 SX is fitted with a state-of-the-art, lightweight 35 mm USD WP XACT AER fork. With 215 mm of wheel travel, the air unit in the left fork leg can also be adjusted easily using an air pump for rider preference, weight, or track conditions. At the rear, an all-new fully-adjustable WP XACT monoshock boasts a new mounting point on the frame making it more compact, providing the perfect balance and damping characteristics to match the fork.

BRAKES

Bringing the 2024 KTM 65 SX to a stop comes courtesy of floating brake calipers from Formula, with a 198 mm wave disc up front and a 180 mm wave disc at the rear. This brake assembly combination reduces wear and ensures maximum reliability and durability, while a new forged rear brake lever provides the ideal rider feel and durability.

EXHAUST

A completely new exhaust system features the same manufacturing process as the full-size 2-stroke KTM SX range, with improved overall quality and performance. This has resulted in massive improvements in thermodynamics. Moreover, improved sealing of the silencer end cap and a new rubber between the header pipe and silencer add another level of quality to the new exhaust system. The silencer has also been updated and now comes with a black anodized finish and a signature 'Braaaaap!'.

RADIATOR

Using state-of-the-art Pankl radiators inspired by the full-size KTM SX range, the 2024 KTM 65 SX features the same basic design with all the hardcore cooling properties. The highlight of the new cooling concept with the two all-new radiators is the tubing connecting the radiators, which significantly improves cooling efficiency, keeping this little motor perfectly chilled under hard charges.

HOUR METER

Keep track of engine hours easily, with an hour meter now mounted at the same position behind the front number plate – as on the full-size KTM SX models. This makes for easier reading and has a lower risk of dirt and water fouling up the display.

GRAPHICS

Modeled after the full-size motocross bikes, the KTM 65 SX features typical READY TO RACE graphics using the time-proven in-mold application process to ensure the best durability and quality.
