PERFORMANCE

The 2024 KTM 50 SX features a modern and compact engine using the latest 2-stroke technology. Using a 3-shaft design, the crankshaft is positioned near the center of gravity, which not only benefits mass centralization but also creates the ideal intake angle into the reed valve for top-level performance. An independent cylinder blank allows for a completely new cylinder design, with increased power.

POWER-REDUCTION KITS

For absolute beginners, the KTM POWERPARTS catalog now offers a choice of two power-reduction kits. The first allows for a entry-level, moderate and controllable power reduction to 4hp, with the second allowing for a more intermediate power kit unleashing 8hp for mid-level riding levels.

CLUTCH

The 2024 KTM 50 SX is fitted with an updated and reworked automatic centrifugal clutch reducing the complexity for younger riders, and helping to boost riding confidence. The multi-disc clutch delivers a precise and predictable power delivery across the RPM range. It can be set to suit rider preferences or track conditions without using any special tools. Also, a reinforced clutch basket provides Improved durability, wear, and consistent performance.

SPARK PLUG

There's no more worrying about breaking the plug, thanks to the 2024 KTM 50 SX featuring a new spark plug from BRISK with a longer thread. Also, thanks to this innovation from BRISK, the part number is printed on the spark plugs for easy reading.

TANK

The KTM 50 SX is ready to fuel the fire in your little ripper with an updated tank design to compliment the new frame concept and bodywork.

AIRBOX AND FILTER

An all-new airbox concept features a conventional suction sleeve made from a hard-wearing polyamide instead of rubber and a Twin Air filter mounting system that now features snap locks for easy and intuitive mounting. The Twin Air filter is also placed under the seat and is easily accessible without any tools by simply removing the seat. It also features improved dirt intrusion resistance, with no more dirt falling into the intake tract when changing the filter.

ERGONOMICS

Mimicking the full-size KTM SX range, the KTM 50 SX features the same advancements found in the larger KTM SX range. Slimmer, sleeker, and better suited to standing on the pegs, the side panels now work much better with young riders’ boots, allowing a proper squeezing of the bike when standing up. The front number plate incorporates plastic flaps to protect the lower triple clamps from roost, while the tank spoiler features a bicomponent technology featuring the KTM-specific texture on the upper part. Side number plates are kept as close to the frame as possible, with the general seat line sitting slightly flatter compared to the old generation.

FRAME

Right, this is a big one. For the first time ever on a 50cc, the 2024 KTM 50 SX boasts an all-new high-strength chromium molybdenum steel frame design with forged connecting parts integrated into the frame. This together with carefully calculated parameters of longitudinal flex and torsional rigidity, allow tailormade stiffness and an unprecedented quality of the Mini frame could be achieved. The new frame layout features a typical MX design without any cross tube behind the steering head. Like our full-size models, the rear shock mount is separated from the main upper frame tube. The frame now also comes with frame protectors as standard.

HANDLEBARS & GRIPS

Hold on tight! The high-quality, tapered, black handlebar is made of lightweight aluminum alloy and ensures top stability, vibration damping, and control. An entirely new bend and profile is designed specifically to meet the needs of young riders, with ODI grips on the left, and a vulcanized ODI grip on the right-side throttle assembly, adding to the overall quality. A crash pad on the handlebar protects the rider from any rough contact or impact with the bars.

WHEELS & TIRES

Rolling off the race rig and into the pit lane, the 2024 KTM 50 SX uses lightweight, black anodized, aluminum rims just like the full-size KTM SX range. These provide the highest levels of strength and reliability, while MAXXIS MX-ST tires deliver outstanding performance on any terrain, along with exceptional straight-line stability.

FOOTPEGS

All-new, “no-dirt” footrests offer a bigger surface area for improved grip while standing on the pegs, and are less susceptible to hooking up in deep ruts, take-offs when scrubbing, or track barriers.

SUSPENSION

Featuring the latest in suspension technology, the KTM 50 SX is fitted with a state-of-the-art, lightweight 35mm USD WP XACT AER fork. With 205mm of wheel travel, the air unit in the left fork leg can also be adjusted easily using an air pump for rider preference, rider weight, or track conditions. At the rear, an all-new fully-adjustable WP XACT monoshock boasts new mounting points on the frame, making it more compact, and providing the perfect balance and damping characteristics to match the fork.

BRAKES

Featuring the same level of technology offered on the full-size KTM SX range, the 2024 KTM 50 SX is fitted with dramatically improved hydraulic brake calipers and state-of-the-art front and rear waved brake discs. This system ensures advanced braking feel and unmatched stopping performance in all conditions, specifically on wet or muddy tracks, with improved durability and brake pad longevity.

EXHAUST

A completely new exhaust system, features the same manufacturing process as the full-size 2-stroke KTM SX range, with improved overall quality and performance. This has resulted in massive improvements in thermodynamics. Moreover, improved sealing of the silencer end cap and a new rubber between the header pipe and silencer adds another level of quality to the new exhaust system. The silencer has also been updated and now comes with a black anodized finish and a signature 'Braaaaap!'.

RADIATOR

Featuring state-of-the-art technology and superior cooling power, the 2024 KTM 50 SX uses one large radiator with more capacity instead of two smaller separate ones. This concept allows for better integration of the radiator into the frame and the tank spoilers to channel air through the cooling fins efficiently.

HOUR METER

Keep track of engine hours easily, with an hour meter now mounted at the same position behind the front number plate – as on the full-size KTM SX models. This makes for easier reading and has a lower risk of dirt and water fowling up the display.

GRAPHICS

Modeled after the full-size motocross bikes, the KTM 50 SX features typical READY TO RACE graphics using the time-proven in-mold application process to ensure the best durability and quality.
